VS-Z7-200
Our Sintered PE Filter Element is engineered from ultra-high-quality polyethylene raw materials through a precision sintering process. This results in a robust, porous structure specifically designed for high-performance filtration in various industrial environments. Its sleek, white cylindrical design ensures maximum surface area for effective contaminant removal while maintaining structural integrity under pressure.
1, Superior Material Quality: Made from non-toxic and odorless PE, ensuring safety for diverse applications.
2, High Durability: Despite its lightweight nature, the element is exceptionally sturdy and can withstand significant filtration pressure without deforming.
3, Precision Performance: Offers a consistent 5µm filtration accuracy with a 95% efficiency rate, ideal for sensitive equipment protection.
4, Chemical Stability: Resistant to a wide range of chemicals, making it suitable for aggressive working mediums like Nitrogen and Air.
| Item | Specification |
| Working Medium | Air, Nitrogen |
| Working Pressure | 100 kPa to 1.0 MPa (at 20°C) |
| Working Temperature | 0 to 60°C |
| Filtration Precision | 5 µm (95% efficiency) |
| Material | Sintered Resin (PE) |
| Dimensions | OD Ø16 x ID Ø12 x L25 mm |
This versatile filter element is widely utilized in:
Pneumatic Systems: Protecting sensitive valves and actuators from dust and particles.
Vacuum Systems: Ideal for vacuum filtration and protecting vacuum pumps.
Water Treatment: Removing fine sediments in liquid filtration setups.
Gas Purification: Ensuring clean air or nitrogen flow in laboratory or industrial lines.
Installation: Ensure the filter housing is depressurized before insertion.
Orientation: Place the element securely onto the support core within the filter housing.
Sealing: Verify that O-rings or seals are intact to prevent bypass.
Monitoring: Regularly check the pressure drop across the filter to determine when replacement is necessary.
Stop operation and return internal pressure to atmospheric levels.
Slide the anti-reverse block and rotate the housing cover counterclockwise.
Remove the old element; blow air through the housing to clear debris.
Insert the new element and securely lock the cover.
Q: Can this filter be cleaned and reused?
A: While some surface debris can be blown off, we recommend replacement for optimal filtration efficiency once the pressure drop is too high.
Q: Is it suitable for high-temperature liquids?
A: The maximum working temperature is 60°C. For higher temperatures, please consult us for alternative materials like UHMWPE or PA.
Q: What is the filtration efficiency?
A: It provides a 95% efficiency for particles as small as 5 micrometers.
