| Quantity: | |
|---|---|
Our 20-inch Slim Antibacterial Filter Cartridge offers an extended filtration path and high flow rates for large-capacity water treatment systems. Its sleek design incorporates antimicrobial technology, making it perfect for industrial and commercial applications where maintaining high throughput without microbial contamination is critical. This cartridge delivers sustained protection against bacteria throughout its long service life.
Extended Service Life: The 20-inch length provides a larger filtration area, resulting in higher dirt-holding capacity and significantly longer change-out intervals compared to standard 10-inch cartridges.
High-Flow Design: Engineered for minimal pressure drop, allowing for greater flow rates with lower energy consumption, ideal for central filtration systems.
System-Wide Bio-Protection: The antibacterial property ensures that the filter itself does not contribute to bacterial regrowth, protecting downstream membranes and equipment in multi-stage systems.
Rigorous Structural Integrity: Features a robust inner core and end caps to withstand higher system pressures and flow surges common in industrial settings.
Material | Antimicrobial Polypropylene (PP) |
Color | Blue |
Filtration Accuracy | 1, 5, 10, 20, 30, 50 Micron |
Length | 20" |
Diameter | 2.5" |
Operating Temperature | ≤ 60°C (140°F) |
Max Operating Pressure | 0.4 MPa (58 PSI) |
PH Range | 1 - 13 |
Surface | Dot |
High-flow pre-filtration for reverse osmosis systems in factories.
Main filtration line in commercial water purification units.
Recirculating water systems requiring bacterial control.
Pre-treatment for large-scale UV sterilizers.
Ensure the filter housing is designed for 20-inch cartridges. Secure the cartridge properly to prevent vibration. Monitor inlet and outlet pressure gauges; replace when the differential pressure exceeds 0.25 MPa.
Q: What housing do I need for this 20-inch filter?
A: You will need a filter housing specifically designed to accommodate a 20-inch long cartridge, which is larger than the standard 10-inch model.
Q: How much longer does it last compared to a 10-inch filter?
A: It can typically last 2-3 times longer, depending on your water quality. It holds roughly double the filtration media, greatly extending its capacity.
Q: Can I use it for filtering rainwater?
A: Yes, it is an excellent choice for pre-filtering rainwater collected from roofs to remove leaves, debris, and particulates before further purification.
