Our Orange Surface Melt Blown Filter Cartridge is characterized by its unique orange-peel-like textured exterior. This specially engineered surface is not merely a color but a functional design that increases the effective filtration area and creates turbulent flow. This enhances particle capture efficiency and dirt-holding capacity, making it a superior performer for standard to challenging sediment filtration tasks.
Increased Effective Filtration Area: The distinctive orange-peel texture creates a larger surface area compared to a smooth filter, providing more sites for contaminant capture and extending the service life.
Promotes Turbulent Flow: The uneven surface disrupts laminar flow, causing water to mix more vigorously. This "scrubbing" action helps to prevent contaminants from forming a dense cake on the surface, allowing particles to be carried deeper into the media for more effective depth filtration.
Balanced Performance Enhancement: It offers a significant improvement in dirt loading and filtration efficiency over plain-surface filters, while maintaining a cost-effective profile compared to more deeply grooved models.
Delayed Surface Blindness: The textured surface helps distribute the contaminant load more evenly, reducing the risk of premature clogging at the initial contact point.
Material | 100% Polypropylene |
Filtration Accuracy | 1–50μm |
Length | 10″ to 40″ |
Diameter | 2.5″ or 4.5″ |
Operating Temperature | ≤ 60°C |
Max Pressure | 0.4 MPa |
End Cap | PP, plain/threaded |
NSF/ANSI 42 certified |
Pre-filtration for water with moderate to high sediment load.
Applications where a standard plain filter clogs too quickly.
Protecting pumps, UV sterilizers, and other sensitive equipment from particulate matter.
Industrial process water treatment.
Install like a standard cartridge. The textured surface requires no special handling. Monitor the pressure drop; replace the cartridge when the differential pressure increases by 0.25-0.3 MPa over the clean pressure.
Q: How often should I replace the melt blown cartridge?
A: Typically every 3–6 months, depending on water quality and usage. A noticeable drop in water pressure indicates it's time for replacement.
Q: Can this cartridge be used with hot water?
A: No, it is designed for cold water applications only. Maximum operating temperature is 60°C.
Q: Does it remove chemicals or bacteria?
A: No, it is designed for sediment removal only. For chemical or microbial removal, use with activated carbon or UV systems.
